Ceramic XRD Tubes – Ceramic Series X-Ray Tubes for X-Ray Diffractometers

AXT can supply a comprehensive range of ceramic x-ray tubes for x-ray diffractometers. Our range of ceramic XRD tubes is divided into the following ranges:

•  Normal Focus Ceramic XRD Tubes – 1.0mm x 10mm focal spot
•  Fine Focus Ceramic XRD Tubes – 0.4mm x 8.0mm focal spot
•  Long Fine Focus Ceramic XRD Tubes – 0.4mm x 12mm focal spot

To request a quote for a ceramic XRD tube, locate your tube type and click the corresponding “Request A Quote” button. Please provide as much information as you
can to help us generate your quotation as quickly as possible.

If you do not know which type of x-ray tube you require please fill in this form. and we will source the correct x-ray tube for your particular x-ray diffractometer.
Note: AXT can also supply glass XRD tubes and offer a comprehensive range of these x-ray tubes to suit all popular makes and models of x-ray diffractometers.

Ceramic XRD X-Ray Tubes - Normal Focus 1.0mm x 10.0 mm Focal Spot Compatibility Chart

Anode Material	Max Power (W)	Anode Length	Philips/PANalytical^	Siemens/Bruker	Enraf^	Seifert^	Thales	Click for Quote
Copper Cu	2200	Short	PW 2233/20	KFN-Cu-2K/4K	EN3502.243	9365700	MC61-10-CU
		Long	PW 2243/20	KFN-Cu-2L/4L		9365710	MC61-10-CU + Adaptor
Molybdenum Mo	3000	Short	PW 2235/20	KFN-Mo-2K/4K	EN3502.245	9365740	MC61-10-MO
		Long	PW 2245/20	KFN-Mo-2L/4L		9365750	MC61-10-MO + Adaptor
Tungsten W	3000	Short	PW 2234/20	KFN-W-4K		9365720	MC61-10-W
		Long	PW 2244/20	KFN-W-4L		9365730	MC61-10-W + Adaptor

^ Glass series x-ray tube
Made in France

Ceramic XRD X-Ray Tubes - Fine Focus 0.4mm x 8.0 mm Focal Spot Compatibility Chart

Anode Material	Max Power (W)	Anode Length	Philips/PANalytical^	Siemens/Bruker	Enraf^	Seifert^	Thales	Click for Quote
Copper Cu	2200	Short	PW 2213/20	KFF-Cu-2K/4K	EN3502.223	9365560	MC61-04-CU
		Long	PW 2223/20	KFF-Cu-2L/4L		9365570	MC61-04-CU + Adaptor
Molybdenum Mo	3000	Short	PW 2215/20	KFF-Mo-2K/4K	EN3502.225	9365600	MC61-04-MO
		Long	PW 2225/20	KFF-Mo-2L/4L		9365610	MC61-04-MO + Adaptor
Tungsten W	3000	Short	PW 2214/20	KFF-W-4K		9365580	MC61-04-W
		Long	PW 2224/20	KFF-W-4L		9365680	MC61-04-W + Adaptor

^ Glass series x-ray tube
Made in France

Long Fine Focus XRD X-Ray Tubes - 0.4mm x 12mm Focal Spot Compatibility Chart

Anode Material	Max Power (W)	Anode Length	Philips/PANalytical^	Siemens/Bruker	Seifert^	Thales	Part No	Click For Quote
Cobolt Co	1800	Short	PW2278/20	KFL-Cu-2K/4K	9365480		XRD60C12COS
		Long	PW2288/20	KFL-Cu-2L/4L	9365490		XRD60C12COL
Chrome Cr	1900	Short	PW2278/20		9365520		XRD60C12CRS
		Long	PW2288/20		9365530		XRD60C12CRL
Copper Cu	2200	Short	PW2273/20		9365420	MC61-04x12-CU	XRD60C12CUS
		Long	PW2283/20		9365430	MC61-04x12-CU + Adaptor	XRD60C12CUL
Iron Fe	1000	Short	PW2277/20		9365500		XRD60C12FES
		Long	PW2287/20		9365510		XRD60C12FEL
Molybdenum Mo	3000	Short	PW2275/20	KFL-Mo-2K/4K	9365460	MC61-04x12-MO	XRD60C12MOS
		Long	PW2285/20	KFL-Mo-2L/4L	9365470	MC61-04x12-MO + Adaptor	XRD60C12MOL
Tungsten W	3000	Short	PW2274/20			MC61-04x12-W
		Long	PW2284/20			MC61-04x12-W + Adaptor

^ Glass series x-ray tube
Made in France
